FileFormats-Medimage¶

FileFormats-Medimage is an extension of the FileFormats package for the file formats used in medical imaging, particularly in medical imaging research. It adds format classes for:

DICOM: single files, and series of them, either in a directory or as a set of files
NIfTI: NIfTI-1/2, gzipped, with BIDS JSON side-cars, and with FSL-style diffusion encodings
other image formats from neuroimaging and image analysis tools: Analyze, FreeSurfer MGH, NRRD, MetaImage, VTK, GIPL and GIFTI surfaces
raw data: MRI k-space and spectroscopy, and PET list-mode, sinograms, count rates and normalisation
deidentification recipes for the deid package, with declarative side-cars for values that have to be computed (see Deidentification)

As in the main package, the format classes have no dependencies. They can be used to detect and validate files, and as type hints in data workflows. Classifiers describing the image contents, e.g. the modality (Mri, Pet), contrast (T1w, Flair) or anatomy (Brain), can be attached to formats with square brackets, e.g. NiftiGz[T1w].

Functionality that needs external libraries lives in the separate fileformats-medimage-extras package. It includes reading image data and headers, generating sample data, converters between formats (e.g. DICOM to NIfTI with dcm2niix), and the deidentification of DICOMs. See Extras for the hooks it implements.

Installation¶

FileFormats-Medimage can be installed for Python >= 3.11 using pip

$ python3 -m pip install fileformats-medimage

This installs the format classes, which have no dependencies other than FileFormats itself. To read image data and metadata, convert between formats and deidentify images, also install the extras package

$ python3 -m pip install fileformats-medimage-extras

The converters wrap command-line tools, which need to be installed separately. dcm2niix converts DICOM to NIfTI, and MRtrix3 converts images to Analyze and MRtrix formats (see Converters). On Ubuntu, for example, they can be installed with

$ sudo apt install libopenjp2-7
$ curl -fLO https://github.com/rordenlab/dcm2niix/releases/latest/download/dcm2niix_lnx.zip
$ unzip dcm2niix_lnx.zip && sudo mv dcm2niix /usr/local/bin
$ conda install -c mrtrix3 mrtrix3

(on macOS, use Homebrew in place of apt).

License¶

This work is licensed under a Creative Commons Attribution 4.0 International License

Acknowledgements¶

The authors acknowledge the facilities and scientific and technical assistance of the National Imaging Facility, a National Collaborative Research Infrastructure Strategy (NCRIS) capability.
